| Model |
TC41021- S |
TC4328- S |
| Detection |
Vehicle: 17400m |
Vehicle: 18000m |
| |
Human: 6800m |
Human: 8000m |
| Recognition |
Vehicle: 4800m |
Vehicle: 6000m |
| |
Human: 1800m |
Human: 2600m |
| Sensor |
1,Detector:5th generation UFPA Vox Detector ;
2,Resolution:336×256,(640X512 optional)
3,NETD:50mK(@25℃ F1.0)
4,Spectral range:7.5～14μm
|
| NETD |
50mK(@25℃ F1.0) |
| Focal length |
1,Length: 21～210mm
2,FOV:16°×12°～1.6°×1.2°
3,Motorized zoom,focus(auto focus optional )
4,AS+DOE advanced optical design, high infrared transmission;
5,Applied 3CAM high precision design;
|
1,Length: 95/285mm
2,FOV:3.4°×2.4°/1.1°×0.8°
3,Motorized zoom, auto focus ;
4,AS+DOE advanced optical design, high infrared transmission;
5,Applied 3CAM high precision design; Dual focal fast switch ;
|
| IFOV |
0.08～0.85mrad |
0.06～0.18mrad |
| Image processing |
1. stable operational temperature, starting time less than 4 seconds |
| 2. SDE digital image processing |
| 3. 10 pseudo color and B/W, B/W inverse |
| 4. AGC |
| 5. 2X digital amplification |
| Housing |
1,Material:aluminum alloy housing,waterproof;
2,Structure:Integral single window design ;
3,Surface:PTA coating,anti sea water corrosion;
4,Sealing rate:IP66
5,Built-in temperature controller,thermal balance design;
6,Interface:aviation waterproof connector ;
|
| PTZ(optional) |
1,Load:50kg level digital PT ;
2,Angle:pan 0～360°,tilt -45°～+45°
3,Speed:0.01～30°/S high precision variable speed control and locking ;
4,Preset:80 presets,support lens zoom and focus memory,variable speed scanning 0～30°/S ,support apple peel scanning function;
5,Protocol:Pelco-P,Pelco-D
6,Baud rate:2400,4800,9600,19200 optional ;
|
| Consumption ,weight |
1,Consumption(PT included):min.40W,max.120W
2,weight(PT included):≤40kg
|
| Interface |
1. RS-485(PELCO D protocol, baud rate 2400bps), RS-232(option) |
| 2. Remote OSD setting |
| 3. PAL/NTSC video output |
| 4. AC24V( DC12V option) |
| 5. Waterproof connector |
| Environment indicator |
1,Working temperature:-25℃～+55℃(-40℃ optional)
2,Storage temperature:-35℃～+75℃
3,Humidity:<90%
4,Anti-shock:0.2g(GB/T15211—20135.4 harshest level 2 standard)
5,Anti-resistance:15g(GB/T15211—20135.3 harshest level 3 standard)
6,Anti-lightening:power 4000V,signal 2000V
7,Anti salty:PH6.5～7.2,continuous sprarying 48 hours ;
8,Protection rate:IP66
|
